Cable Magazine
PASSER's Cable Magazine continuously feeds out cable with a preset tension between 1 and 1000N.
In the event of a stop or an unexpected incident in the production line, the magazine provides up to 30 meters of buffer storage. This offers a high level of protection against tension-related cable damage.
The built-in buffer length also ensures exceptional safety against cable breakage or stress even during sudden production stops.
Modular Design
Modular design for customer-specific adaptability
Preset Tension
Preset tension between 1 and 1000N
Risk Mitigation
The magazine provides up to 30m of buffer storageudring production.
Customizable
The magazine can be delivered with various frame configurations and adjustment options including angle adjustments and mounting points, customized to specific requirements.
Technical Specifications
| Max. Line Speed: | 20 m/min |
| Max. Storage Length: | 10m of cable |
| Cable Diameter : | Up to 20mm |
| Bending Radius: | 400mm |
| Platform Height: | Customized to process requirements |
| Tension: | Up to 1000N |
| Rotation: | Optional |
| Standard Equipment: | Load Cell for Constant Tension Reading |
Certifications
-
CE marked for conformity and safety, designed to comply with EU machinery directive EU 2006/42 (From 2027, EU machinery directive 2023/1230 will be governing).
-
2014/35/EU Low Voltage Directive
-
2014/30/EU Electromagnetic Compatibility Directive
